| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | FL SWITCH SF 15TX/FX |
| Approvals | UL Listed, cUL Listed, cULus Listed, UL Listed, cUL Listed, EAC, EAC, cULus Listed |
| Current, Supply | 330 mA |
| Mounting Type | DIN Rail |
| Number of Ports | 16 Port |
| Port, Type | (15) x RJ45, (1) x FO SC Duplex |
| Primary Type | Ethernet Switch |
| Protocol Type | 100 Mbit/s (Full Duplex), 10/100 Mbit/s (RJ45) |
| Series | |
| Special Features | Auto-Negotiation ; Auto-Crossing ; Store and Forward |
| Supply Voltage | 24 VDC |
| Type | Unmanaged Switch |
Overview
Phoenix Contact Factoryline Family of SF and SFN Series Unmanaged Industrial Ethernet Switches:
Ethernet provides maximum freedom for designing your infrastructure. With Factoryline products from Phoenix Contact, you can make the most of all the options offered by Ethernet networks, ensuring unrivaled flexibility, performance, consistency and speed.
You can run standard functions perfectly with our SF and SFN switches. You can choose between devices with a narrow or flat design. Both switch types provide up to 16 ports, transmission speeds of 10/100 Mbps, and redundant power supply. The cables can be secured as an option using mechanical locking. Furthermore, the SFN switches prioritize data packets with the Quality of Service function. For reliable communication in PROFINET networks, they are also available as PROFINET versions with PTCP filter.
Features:
