FEATURES:

• Auto and manual ranging

• Non-contact and single-probe voltage detection

• Beep-Jack™ audible and visible warning to guard against improper A and mA terminal plug in.

• High visibility 6000 count LCD display.

• Capacitance and temperature measurement capability.

• Auto power off, display backlight, analog bar graph

• PC interface capability using optional USB RS-232 cable with  data recording PC software.

• Lifetime Limited Warranty.

SPECIFICATIONS:

• Voltage Measurement: 60mV to 1000V AC/DC

• Amperage Measurement: 600mA to 8A AC/DC

• Resistance: 600Ω to 60MΩ

•Frequency (Hz): 50 ~ 400

• Measurement Category: Cat IV, 300V; Cat III 600V, Cat II 1000V
